Anycut ZKD1000 Double-head Cutting Trolley High Force Cutting Machine CCD Camera Positioning

Brand Name : Anycut

Model Number : ZKD1000

Certification : CE/FCC/RoHS

Place of Origin : Shenzhen

MOQ : 1Piece

Price : $613~827/piece

Payment Terms : T/T,Western Union

Supply Ability : 1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days

Delivery Time : 20~30 work days

Packaging Details : L1250mm*W600mm*H1100mm

Control panel : 5.0 inch touch screen

Motor : Stepper

Max.cutting width : 700mm

Cutting length : Unlimited

Max.cutting speed : 700mm/s

support software : CDR/AI/PS/Contour software/signmaster(optional)

max force : 2000g

Drawing instruction : Automatic recognition DMPI and HPGL

Auto contour cut : Camera

Main board : ARMsmart dual-core chip

Contact Now

Anycut ZKD1000 Double-head Cutting Trolley High Force Cutting Machine CCD Camera Positioning



- Powerful Cutting Performance:

Equip a max cutting width is 700mm,delivers an impressive 2000g cutting force with ±0.01mm accuracy, handling thick or tough materials easily.


- Smart Connectivity:

Offers flexible connectivity via USB, U-disk, and optional WiFi for seamless workflow.


- High Precision & Speed:

Boasts a max cutting speed of 700mm/s and 0.082mm repeatability, ensuring fast, consistent results.


- User-Friendly Interface:

Equipped with a 5.0-inch LCD touch screen for intuitive operation.


- Broad Compatibility:

Supports Windows systems and popular design software (CDR, AI, PS, etc.).



MODEL ZKD1000
Max. media width 1000mm
Max. cutting width 850mm
Packing size L 1360mm*W 400mm*H 440mm
Machine size L 1250mm*W 600mm*H 1100mm
Gross/Net weight 36kgs/30kgs
Control panel 5.0inch LCD touch screen
Motor Stepper
Cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.cutting speed 700mm/s
Max.force 2000g
Main board ARM smart dual-core chip
Auto contour cut Camera
Number of heads 2
Blade type Rowland blade
Floorstand yes
Drawing instruction Automatic recognition DMPI and HPGL
Connect or interface USB cable/Udisk/WIFI(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive),50HZ/60HZ
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows



Anycut ZKD1000 Double-head Cutting Trolley High Force Cutting Machine CCD Camera Positioning



Anycut ZKD1000 Double-head Cutting Trolley High Force Cutting Machine CCD Camera Positioning
